- Additional protection from dirt and liquids
The World’s most innovative Wheel aligner
VAS 701 011 is our answer to an increasingly digital and fast-paced world: ultra-fast, compact, connected
World’s First Web-based wheel aligner
- Compact web-based technology creates more space by replacing the need for trolley with PC
- Stream-to-X: Directly display the software on any TV, PC, laptop or smartphone
- Unleash the full power of connectivity by integrating the VAS 701 011 into your daily workshop processes and systems
Full mobility, infinite possibilities
- Completely wireless thanks to high performance Li-Ion batteries
- Installation on any alignment lift type, above and inground
- Runout compensation in any lift height, from zero to top position
- Permanently use the space in front of the lift for headlight testing and ADAS calibration
Work smarter, not harder
- Get values the second the targets are recognized to immediately spot vehicles involved in accidents
- Measure with any target on any wheel position to save time and eliminate user error
- Active lift control: Our recipe for success for straight steering wheels
- Have the values always in sight from under the vehicle with the four OLED screens on the sensor heads
Putting the customer first
- Easy to understand printouts
- Theme-based printouts (e.g. accident report) instead of one size fits all
- Measurement of all common wheel alignment angles, including vehicle dimensions for easy detection of vehicles involved in accidents
Direct integration of the VAS 701 009 wheel load scales
- Realtime wheel load in the wheel alignment program
- Live display of the cross-load distribution during the entire alignment
- Wheel load distribution and wheel alignment in one step instead of two
- Direct integration of the VAS 701 009 wheel load scales
- 2x VAS 701 011 sensor heads with OLED displays
- Display module for direct streaming to TV, PC, laptop or tablet
- Tablet
- 2x Li-Ion batteries with charging station
- 4 targets
- Wall storage for wheel clamps
- Lift adapter
- Wall board for storage of sensor heads and battery charger
- Steering wheel and brake pedal lock
- 4x filling pieces for turntables
- 2x connecting cable for turntable
- Key Card VAS6767/2
- Key Card vehicle specs
Note: The scope of delivery does not include wheel clamps and turntables. For Porsche vehicles, the self-centering central locking adapters VAS 6918, V.A.G 6830 or V.A.G 6828 should be used. For weighing vehicles during wheel aligner operation, the turning plates VAS 701 009 should be used.
| Electrical connection | 90-264V | 1Ph | 47-63Hz |
|---|---|
| Packaging length | 1080 mm |
| Packaging width | 960 mm |
| Packaging height | 900 mm |
| Gross weight | 100 kg |
| Measuring system | 3D |
| Weight | 80 kg |
| Packaging unit | 1 Palette(s) |
| Data transmission type | kabellos |
| Power consumption | 45 W |
| Accumulator power (electric charge) | 99 Wh |
| Min. tyre size | 525 mm |
| Max. tyre size | 835 mm |
| Load capacity per turntable | 2000 kg |
| Wheel base | 1800 - 4500 mm |
| Electrical connection | 90-264V | 1Ph | 47-63Hz |
|---|---|
| Packaging length | 1080 mm |
| Packaging width | 960 mm |
| Packaging height | 900 mm |
| Gross weight | 100 kg |
| Measuring system | 3D |
| Weight | 80 kg |
| Packaging unit | 1 Palette(s) |
| Data transmission type | kabellos |
|---|---|
| Power consumption | 45 W |
| Accumulator power (electric charge) | 99 Wh |
| Min. tyre size | 525 mm |
| Max. tyre size | 835 mm |
| Load capacity per turntable | 2000 kg |
| Wheel base | 1800 - 4500 mm |
-
Protective rubber cover for aluminum turntable 1690402001 1690402001
-
Dust cover target board | Q.Lign 1690202155 1690202155
Scope of delivery: 1x protective cover
-
VAS 701011/1 | Set 2x Magnetic clamp for VW Crafter | 130mm & 205mm bolt circles 1690101084 1690101084
Set of 2 magnetic clamps for the front axle of the VW Crafter with 130mm and 205mm bolt circles. Magnet length: 55mm
-
VAS 701011/2 | ADAS target boards | for VAS 701011 1690201131 1690201131
For ADAS calibration in combination with VAS 701011. Target boards can be permanently installed on the ADAS calibration tool.
Scope of delivery:- 2x ADAS target boards (Coding ID #5 and #6)
- 2x target covers
Compatible with VAS 6430.
-
Mounting set for brake and steering wheel lock (2x) | for wall installation 1690101089 1690101089
-
Vehicle database update Q.Lign | Key Card 1690002022 1690002022
- Access to the newest vehicles specs directly from the OEM
- Authorises the licensing of all IAM vehicle databases for the calender year in which the Key Card has been activated
-
Wheel chock set 2 pcs. 1692000156 1692000156
Scope of delivery:
- 2 x Wheel chock
-
Printer for Beissbarth trolleys 1693770415 1693770415
-
Trolley VAS 701 011/3 with 27"monitor | for VAS 701 011 1690201130 1690201130
-
RaceScales | VAS 701009 | Precision turntable with load cells | 433Mhz 1690400100 1690400100
Electronic corner weight scales: Optimal adjustment of the chassis in connection with the wheel alignment
The electronic corner weight scales carry out high-precision weight distribution on the vehicle. In connection with the wheel alignment, the chassis can be optimally adjusted. This provides maximum levels of grip and better overall handling of the vehicle.
By the help of the corner weight scales the static weight distribution as well as the center of gravity optimization are integrated into to wheel alignment process. This not only ensures a stable and levelled working surface for optimal measurement results but also allows the immediate re-adjustment of camber, caster, and toe settings after the change in ride height. In motorsports the RaceScales ensure best race settings of the vehicle for faster lap times.
Digital corner balance scales:
- High precision for best measurement results
- High performance lithium polymer battery, wireless
- Seamless integration in all common wheel alignment lifts
- Compatible with all Beissbarth wheel aligners and third-party systems
- Intuitive software with clear display of measured values
- Always-on-top mini screen with live values of the four wheel weights
Software functions for optimal weight distribution:
- Weight distribution per wheel
- Weight distribution per axle
- Difference between front and rear
- Weight distribution per side
- Difference between left and right
- Cross Weight
- Cross Weight in %
- Total weight
- Live center of gravity
- Weighing protocol with company and customer information
Features wheel alignment turntables:
- With steering sensor for maximum steer measurement with CCD, Touchless, and Q.Lign wheel aligner
- Very high quality and durability
- Steel balls for reduced friction and higher accuracy
- Compatible with all common wheel alignment lifts
- Seamless integration in wheel alignment lifts without fixed rear sliding base
-
Tablet | Android | 10.1" 1693770644 1693770644
Incl. protection case
-
Battery for Q.Lign | Li-Ion | 99 Wh 1690203053 1690203053
-
Drive-on ramps for two aluminum turntables 1690701052 1690701052
- Drive-on ramps for turntables including connecting piece and drive off protection
- Enables rolling compensation on lifts without embedded turntables
This product is suitable for two turntables.
-
Drive-on ramps for turntables and sliding plates 1690401008 1690401008
- Set of Drive-on ramps for turntables and sliding plates
- Suitable for lifts without cutouts for turntables or sliding plates, e.g. MOT lifts
-
Adapter for Consul alignment lifts | for Q.Lign and Easy3D 1690701311 1690701311
- Used to attach Beissbarth lift adapters to wheel alignment lifts without straight side walls
- Suitable for Easy 3D lift adapter 1690701231
- Suitable for Q.Lign lift adapters 1690201122 and 1690201035
- Fits Beissbarth lifts VLH 4245 and VLH 4345, as well as Consul 4-post lifts with wheel alignment kit
-
Electronic aluminum turntable without connecting cable | Precision 1690401013 1690401013
- Enables full steering lock on CCD and Touchless aligner
- Very high quality and lifetime in workshop environment
- Precision turntable without connecting cable
- Steel balls for minimal friction and maximum precision
-
Central Clamp VAG 6828 | Porsche Carrera GT 1690301002 1690301002
- Quick and secure mounting on the vehicle
- Reduces clamping errors
- Official VW special tool: VAG 6828
-
Central Clamp VAS 6830 | Porsche 911 GT3 and Turbo ASE 485 233 00 000 ASE 485 233 00 000
- Special tool for Porsche 911 Turbo since 2009 and Porsche 911 GT3 since 2010
- Quick and secure mounting on the vehicle
- Reduces clamping errors
- Official VW special tool: VAS 6830
-
Self-centering quick clamp VAS 6918 for Porsche ASE 485 237 00 000 ASE 485 237 00 000
- Attaches to the center hole of the rim
- Quick and secure mounting on the vehicle
- Reduces clamping errors
- Official VW special tool: VAS 6918
- Not suited for Porsche vehicles with center wheel bolt!
-
Duo-battery charging station for Q.Lign | incl. accessories 1690201069 1690201069
-
VAS 6767/2 | VW Vehicle Specs Update ASE42322700000 ASE42322700000
Highlights & Key Features:
- Direct Manufacturer Data: Official vehicle data provided directly by Volkswagen AG for the entire VW Group (VW, Audi, SEAT, CUPRA, Škoda, etc.).
- Comprehensive Coverage: Includes specifications for wheel alignment and calibration of predictive driver assistance systems (camera, radar, LiDAR, night vision).
- 365 Days Validity: Unlimited licensing for new data releases within 365 days from activation in the Beissbarth Software Center.
- Simple Activation: Key Card with a scratch-off code for fast online redemption at Beissbarth.com/keycard.
Product Description:
Keep your alignment and ADAS calibration equipment up to date with official manufacturer specs. This Key Card grants access to complete vehicle datasets across the entire Volkswagen Group. It includes all required alignment parameters as well as precise calibration data for predictive Advanced Driver Assistance Systems (cameras, radar sensors, LiDAR, and night vision systems).
Activation & Redemption:The package contains a physical Key Card featuring a scratch-off security field. Redeem the code at the Beissbarth Software Center via Beissbarth.com/keycard. The 365-day validity period starts automatically on the day of activation.
Important Licensing Note:The code licenses individual updates (e.g., v52). Newer updates require re-entering the same code to generate the new license (e.g., v53). This process can be repeated unlimited times during the 365-day validity period of your Key Card.
