- Very high quality and lifetime in workshop environment
Ultimate productivity - vehicle after vehicle
The T-Series builds on the existing Q.Lign platform and focuses entirely on wheel alignment. With Q.Lign T.41, workshops raise the bar even higher and can thus exploit their full service potential.
Measuring at the highest level
- Camera beam measures permanently from a height of 2.8 meters
- No motor, no winch, no wear and tear
- No up, no down, no injuries or damage
- No movement, no matter if short or long wheelbases
Everything perfectly in sight
- Four wheels, four cameras
- Separate camera for the rear axle for more accurate toe values on the front axle
- Install anywhere within 1.8 to 3.3 meters of the front axle
- Measure and adjust from 0 to 2 meters platform height at any time
Work smarter, not harder
- All targets work on any wheel reduces setup times and setup errors
- Active MEMS Technology: Constant measurement against gravity for uncompromising accuracy
- Caster sweep at floor level without the need for a stool or ladder
- Access to clear and easy-to-understand PDF reports from anywhere inside your shop
The world's first web-based wheel aligner
- Eliminates need for trolley and PC and creates more space
- Incredibly efficient with up to 95% power savings compared to PC-based systems
- Stream-to-X: Access software on any TV, PC, laptop, tablet or smartphone
- Intuitive software, streamlined operations, more productivity
- Easy integration of Q.Lign into your shop's daily processes and system
Q.Grip clamps: the last step before Touchless
- 5x faster than conventional clamps
- No removal of hubcaps
- No scratching of rims
- From 21" to 33" in under a second, no know twisting
Space requirement
- Minimum height of 2800mm
- Minimum clearance of 2800mm on four-post lifts
- Camera beam with 4 cameras
- Column with tray
- Q.Lign display module
- 4x targets with AutoID
- 27" monitor, keyboard, mouse
- Brake lock and steering wheel lock
- Front turnplates and filling pieces
- Q.Grip clamps (525-835mm wheel diameter)
- Storage for Q.Grips
- Key Card for international vehicle specs
| Electrical connection | 90-264V | 1Ph | 47-63Hz |
|---|---|
| Packaging length | 2950 mm |
| Packaging width | 820 mm |
| Packaging height | 540 mm |
| Gross weight | 170 kg |
| Measuring system | 3D mit Messbalken (fixiert) |
| Weight | 119 kg |
| Packaging unit | 1 |
| Data transmission type | kabellos |
| Distance camera - center of turntable | 1800 - 3300 mm |
| Clearance front posts of lift min. | 2800 mm |
| Display size | 10 " |
| Max. clamping capacity | 835 mm |
| Min. clamping capacity | 525 mm |
| Power consumption | 65 W |
| Set-up width | 2595 mm |
| Sensor count | 4 Stück |
| Wheel base | 1750 - 4600 mm |
| Set-up height | 2745 mm |
| Electrical connection | 90-264V | 1Ph | 47-63Hz |
|---|---|
| Packaging length | 2950 mm |
| Packaging width | 820 mm |
| Packaging height | 540 mm |
| Gross weight | 170 kg |
| Measuring system | 3D mit Messbalken (fixiert) |
| Weight | 119 kg |
| Packaging unit | 1 |
| Data transmission type | kabellos |
| Distance camera - center of turntable | 1800 - 3300 mm |
| Clearance front posts of lift min. | 2800 mm |
|---|---|
| Display size | 10 " |
| Max. clamping capacity | 835 mm |
| Min. clamping capacity | 525 mm |
| Power consumption | 65 W |
| Set-up width | 2595 mm |
| Sensor count | 4 Stück |
| Wheel base | 1750 - 4600 mm |
| Set-up height | 2745 mm |
- Mechanical aluminum turntable Standard16905010011690501001
- ProClamp wheel clamp | 13 - 23" | 1 pc16901000011690100001
- Rim clamping range: 12 - 23"
- Wheel clamping range: 490 - 884mm
- Magnetic clamps for wheel bolts | 75mm16907015081690701508
- Quick and gentle attachment on wheel bolts instead of the rim
- Secure and central hold for ultimate precision
- Suited for 3/4/5/6 hole rims
- Magnetic clamps for wheel bolts | 100mm16907015211690701521
- Quick and gentle attachment on wheel bolts instead of the rim
- Secure and central hold for ultimate precision
- Suited for 3/4/5/6 hole rims
- Storage tray | Q.Lign T-Series16908020491690802049
Additional storage tray on the column for a printer or accessories. 600 x 300 mm
- Filling piece (1x) for aluminum turntable16901022111690102211
- Mounting set for MultiFit (4x) | for wall installation16901010941690101094
- Mounting set for OE quick clamps (4x) | for wall installation16901010901690101090
- Mounting set for brake and steering wheel lock (2x) | for wall installation16901010891690101089
- Accessory cart | for OE quick clamps16901011271690101127
For storing 4x OE quick clamps, brake locks, and steering wheel locks
- Accessory cart | MultiFit clamps16901011291690101129
For storing 4x MultiFit clamps, brake locks, and steering wheel locks
- Vehicle database update Q.Lign | Key Card16900020221690002022
- Access to the newest vehicles specs directly from the OEM
- Authorises the licensing of all IAM vehicle databases for the calender year in which the Key Card has been activated
- Accessory Cart | for Magnetic Clamps16901011281690101128
For storing 4x magnetic clamps, brake lock, and steering wheel lock
- Bracket set for magnetic clamps (4x) | for wall installation16901010921690101092
- Self-centering quick clamp | for Lamborghini89003800168900380016
- Attaches to the center bolt of the rim
- Quick and secure mounting on the vehicle
- Reduces clamping errors
- Self-centering quick clamp VAS 6829 for PorscheASE 485 232 00 000ASE 485 232 00 000
- Attaches to the center hole of the rim
- Quick and secure mounting on the vehicle
- Reduces clamping errors
- Official VW special tool: VAS 6829
- Not suited for Porsche vehicles with center wheel bolt!
- Mechanical aluminum turntable Precision16904010281690401028
- Very high quality and lifetime in workshop environment
- Steel balls for minimal friction and maximum precision
- Multi-Fit wheel clamp with standard claws | 13 - 22" | 4 pcs.16903111121690311112
- High quality claws for gentle attachment to rims
- Torque control for strong hold without deforming the rim
- Extension set for Multi-fit clamps | 23 - 28"16903111131690311113
- Electronic aluminum turntable without connecting cable | Standard16904010111690401011
- Enables full steering lock on CCD and Touchless aligner
- Very high quality and lifetime in workshop environment
- Standard turntable without connecting cable
- Electronic aluminum turntable without connecting cable | Precision16904010131690401013
- Enables full steering lock on CCD and Touchless aligner
- Very high quality and lifetime in workshop environment
- Precision turntable without connecting cable
- Steel balls for minimal friction and maximum precision
- Central clamp Porsche Carrera GT16903010021690301002
- Quick and secure mounting on the vehicle
- Reduces clamping errors
- Official VW special tool: VAG 6828
- Central clamp VAS 6830 Porsche 911 GT3 and TurboASE 485 233 00 000ASE 485 233 00 000
- Special tool for Porsche 911 Turbo since 2009 and Porsche 911 GT3 since 2010
- Quick and secure mounting on the vehicle
- Reduces clamping errors
- Official VW special tool: VAS 6830
- Self-centering quick clamp VAS 6918 for PorscheASE 485 237 00 000ASE 485 237 00 000
- Attaches to the center hole of the rim
- Quick and secure mounting on the vehicle
- Reduces clamping errors
- Official VW special tool: VAS 6918
- Not suited for Porsche vehicles with center wheel bolt!
- Self-centering quick clamp for Tesla16903801611690380161
- Attaches to the center hole of the rim
- Quick and secure mounting on the vehicle
- Reduces clamping errors
- Self-centering quick clamp for Ferrari16903812991690381299
- Attaches to the center hole of the rim
- Quick and secure mounting on the vehicle
- Reduces clamping errors
- Used for wheel alignment and radar calibration - Wheel alignment requires 2 sets (4 clamps in total) - Radar calibration requires 1 set (2 clamps in total)
- Quick clamp Mercedes-Benz | OEM16908010021690801002
- Distance pins sit directly on the wheel hub, a runout compensation is therefore not necessary
- Quick and secure mounting on the vehicles
- For ultimate precision
- Only suited for CCD and Q.Lign systems
- For wheel diameters up to 850mm
- For original Mercedes-Benz rims with pin hole pattern 5x125mm and 5x160mm
- Quick clamp BMW | OEM16908010011690801001
- Distance pins sit directly on the wheel hub, a runout compensation is therefore not necessary
- Quick and secure mounting on the vehicles
- For ultimate precision
- Homologated for BMW
- Only suited for CCD and Q.Lign systems
- Für Raddurchmesser bis 850mm
- For original BMW rims with 4x100mm and 5x120mm pin hole pattern
- Adapter set Q.Grip | for Q.Lign | 4 pcs.16901010101690101010
Q.Grip: The closest you will get to Touchless.
- Mounting of targets in under 5 seconds
- No rim contact, no scratches or damages!
- Instantaneously change between different tyre diameters with our new patented clamping mechanism
- Three arms guarantee safe and precise grip during the complete alignment
- No removal of hubcaps!
- No knob twisting!
- No fixed wheel assignment, position on any wheel!
- Clamping range: 525-835mm / 20.6"-32.8" (wheel diameter)
- Filling piece for aluminum precision turntable16901020411690102041
1x Precision filling piece for one precision turntable.
Required quantity per turntable: 2
