• Adapter for Consul alignment lifts | for Q.Lign and Easy3D 1690701311 1690701311
  • Used to attach Beissbarth lift adapters to wheel alignment lifts without straight side walls
  • Suitable for Easy 3D lift adapter 1690701231
  • Suitable for Q.Lign lift adapters 1690201122 and 1690201035
  • Fits Beissbarth lifts VLH 4245 and VLH 4345, as well as Consul 4-post lifts with wheel alignment kit


• Mounting set for brake and steering wheel lock (2x) | for wall installation 1690101089 1690101089


• Accessory cart | for OE quick clamps 1690101127 1690101127

  For storing 4x OE quick clamps, brake locks, and steering wheel locks


• Accessory cart | MultiFit clamps 1690101129 1690101129

  For storing 4x MultiFit clamps, brake locks, and steering wheel locks


• Vehicle database update Q.Lign | Key Card 1690002022 1690002022
  • Access to the newest vehicles specs directly from the OEM
  • Authorises the licensing of all IAM vehicle databases for the calender year in which the Key Card has been activated


• Accessory Cart | for Magnetic Clamps 1690101128 1690101128

  For storing 4x magnetic clamps, brake lock, and steering wheel lock


• Bracket set for magnetic clamps (4x) | for wall installation 1690101092 1690101092


• Inclinometer and steering wheel level | Mercedes-Benz 1690102231 1690102231

  Mercedes-Benz Inclinometer Combo-Instrument:

  • Measurement: Measurement of the inclination of the control arm and drive shaft with electronic data transfer of measured values to the wheel aligner.
  • Includes: Includes all mounting adapters for the most common Mercedes-Benz models.
  • Function: After the inclination measurement, the inclinometer is inserted into the steering wheel to monitor the steering wheel position throughout the entire alignment process.
  • Reporting: Automatic transfer of the steering wheel position into the measurement report.

  Included adapters for the following vehicles:


  • Cavity adapter: Mercedes E-Class (on the control arm)

  • Crown adapter: Mercedes A-Class, C-Class, S-Class, E-Class (Type W210 and W211), CLA-Class (Type 117), Citan (Type 415, rear axle only)

  • Angle adapter: Mercedes Vaneo (Type 414, 2001–2005)

  • Measuring adapter: Mercedes Citan (Type 415, front axle only)

  • Adapter plate: Mercedes CLK (Type 208, 1997–2003), C-Class (Type 202, 1993–2001)

  Technical Data:

  • Measuring range: ±45∘ from the horizontal

  • Accuracy: 0.1∘ in the range from 0∘ to ±45∘

  • Repeatability: ±0.1∘

  • Operating temperature range: 0∘C to 50∘C

  • Power supply: 3 x 1.5V AA batteries / Service life approx. 20 hours in normal operation at approx. 50% display brightness

  • Bluetooth: 5.2 Low Energy connectivity

  • Weight: 550 grams (without adapter)


• Lift Adaptation Extension (1x) | for wide vehicles on narrow lifts 1690202173 1690202173

  Extension for Q.Lign lift adaptation, for measuring wide vehicles on narrow lifts. 2x required per wheel aligner.


• Printer for Beissbarth trolleys 1693770415 1693770415


• Trolley with 27"monitor | for MB Q.Lign 1690201151 1690201151


• Mounting set for OE quick clamps (4x) | for wall installation 1690101090 1690101090


• Mounting set for MultiFit (4x) | for wall installation 1690101094 1690101094


• Trolley with 27"monitor | for MB Q.Lign 1690201142 1690201142

  Scope of delivery: - Trolley - Monitor arm - 27" monitor


• Toe press bar for Mercedes Benz 1693600001 1693600001


• Power connection cable 10 m 1690203025 1690203025


• Power connection cable 15 m 1690203041 1690203041


• Battery for Q.Lign | Li-Ion | 99 Wh 1690203053 1690203053


• Emergency power box for Q.Lign 1690201030 1690201030
  • Power supply of sensor heads in case of battery failure
  • Mobile use without fixed installation
  • Connection to sensor heads via 10 m (1690203025) or 15 m cable (1690203041)



  Note: Operation additionally requires the 19 V power supply (1693770648) which is included in the battery-powered Q.Lign scope of deliveries.


• Romess inclinometer with standard adapter | 230V 1693770002 1693770002

  For measuring the level of Mercedes-Benz vehicles on the front and rear axle

  • Measuring range: +/-15° with accuracy of +/- 0.1°
  • Interface: RS-232, USB
  • Data transfer: manual (automatic data transfer requires the Romess data transfer and charging unit 1693770003)

  The included standard adapter plate is only required for types 170, 202, 208 and 210.


• Dust cover target board | Q.Lign 1690202155 1690202155

  Scope of delivery: 1x protective cover


• Filling piece (1x) for aluminum turntable 1690102211 1690102211


• Set 4x Magnetic clamp for light trucks and RVs | 6x130mm & 6x205mm bolt circles 1690101083 1690101083

  Set of 4 magnetic clamps for light trucks and RVs. Only for bolt circle diameters 6x130mm and 6x205mm. Magnet length: 55mm


• Romess adapter set for M-Class type W163 1690102216 1690102216

  Accessories for Romess Inclinometer 1693770002

  Scope of Delivery:

  • Intermediate adapter for front axle level measurement for W163 (M-Class)
  • Intermediate adapter for rear axle caster measurement for W163 (M-Class)

  Original part: 09606-65


• VAS 6767/2 | VW Vehicle Specs Update ASE42322700000 ASE42322700000

  Highlights & Key Features:

  • Direct Manufacturer Data: Official vehicle data provided directly by Volkswagen AG for the entire VW Group (VW, Audi, SEAT, CUPRA, Škoda, etc.).
  • Comprehensive Coverage: Includes specifications for wheel alignment and calibration of predictive driver assistance systems (camera, radar, LiDAR, night vision).
  • 365 Days Validity: Unlimited licensing for new data releases within 365 days from activation in the Beissbarth Software Center.
  • Simple Activation: Key Card with a scratch-off code for fast online redemption at Beissbarth.com/keycard.

  Product Description:

  Keep your alignment and ADAS calibration equipment up to date with official manufacturer specs. This Key Card grants access to complete vehicle datasets across the entire Volkswagen Group. It includes all required alignment parameters as well as precise calibration data for predictive Advanced Driver Assistance Systems (cameras, radar sensors, LiDAR, and night vision systems).

  Activation & Redemption:

  The package contains a physical Key Card featuring a scratch-off security field. Redeem the code at the Beissbarth Software Center via Beissbarth.com/keycard. The 365-day validity period starts automatically on the day of activation.

  Important Licensing Note:

  The code licenses individual updates (e.g., v52). Newer updates require re-entering the same code to generate the new license (e.g., v53). This process can be repeated unlimited times during the 365-day validity period of your Key Card.
