Safe and efficient tyre mounting up to 30“
Center clamping with clamping flange- High concentricity
- Prevention of scratches/damage to the rim edge
- Uniform clamping force
- Especially suitable for UHP, run-flat, and large rim diameters
- Mechanically height-adjustable for “Reverse Mount”
Robust mounting column and head
- Automatic tilting via pedal
- Fast vertical and horizontal movement of the mounting arm
- Pneumatic locking
Wheel lift included
- Easier lifting and lowering of the wheel
- Reduced strain on operators
- Wheel weight up to 80 kg
TCX.PRO: Entry-level assist tower, fully equipped for handling stiff UHP and run-flat tyres
- Pneumatic bead pressing roller keeps the bead in the drop center
- Pneumatic assist arm presses the bead into the drop center
- Lower bead loosener disc for demounting stiff and wide tyres
- Rim pressing cone for easier external clamping
High-rigidity construction
- Full metal pedals
- Powerful horizontal arm
- Robust metal front cover
Full control with four pedals
- Pedal control for rotation, bead breaker blade, tilt function, and wheel lift
- Removable pedal unit for easier maintenance
Powerful side bead breaker blade
- Fast bead loosening
- Up to 15“ tyre width
- Three-way adjustable blade
- Pedal-controlled
- Anti-slip rubber protection
- Infinity tyre changer
- Integrated wheel lift
- Pneumatic assist arm TCX.PRO2.5
| Electrical connection | 3x400 V |
|---|---|
| Clamping Tower Height | 670 mm |
| Max. wheel diameter | 1170 mm |
| Max. rim diameter | 30 " |
| Min. rim diameter | 10 " |
| Motor power | 0,9-1,2 kW |
| Max. rim width | 17 " |
| Rotation speed | 8-16 U/min |
| Operating pressure | 8-10 bar |
| Set-up width | 1260 mm |
| Set-up length | 1850 mm |
| Set-up height | 1950 mm |
| Electrical connection | 3x400 V |
|---|---|
| Clamping Tower Height | 670 mm |
| Max. wheel diameter | 1170 mm |
| Max. rim diameter | 30 " |
| Min. rim diameter | 10 " |
| Motor power | 0,9-1,2 kW |
| Max. rim width | 17 " |
| Rotation speed | 8-16 U/min |
|---|---|
| Operating pressure | 8-10 bar |
| Set-up width | 1260 mm |
| Set-up length | 1850 mm |
| Set-up height | 1950 mm |
- Storage kit | for TC22, TC45 and TC47L16924020141692402014
- Extension for drive pin | Center Post16924021661692402166
Extension for drive pin for proper clamping when rotation and torque are applied
- Rubber protection | for center clamping 16924022141692402214
Only for machines with center clamping
- Cone | for light trucks 16924022131692402213
Only for machines with center clamping
- Spacer | for light trucks 16924022151692402215
Only for machines with center clamping
- Flange | for reverse-mounting rims and without central hole 16924020241692402024
Only for machines with center clamping
- BeadLock Pro | with extension 16924020031692402003
Prevents hard tyres from rotating on the rim and protects TPMS sensors during mounting phase. Includes extension for reversed rim mounting and tyre changes with center clamping.
- Roller bed | for TC22, TC45 and TC47L16924020361692402036
- Bead clamp 16924020311692402031
- Protection for drive pin extension | Center Post16924021831692402183
Protection for drive pin extension 1692402166
