- Levelable rail system for above and inground installation)
- Length: 3 meters
- Complies with the latest requirements placed on test areas in workshops: meets the requirements of vehicle manufacturers as well as the requirements of the general-inspection headlight-test directive
- Height differences of up to 30 mm can be compensated together with the headlight aiming device trolley
- Long lifetime
- High-quality, robust processing
- Precisely guided steel wheels: for precise measurements and adjustments, a one-time alignment with the vehicle is sufficient (time saving!)
- Steel wheels are included in scope of delivery
- Optional expandable to 4.5 m (see accessories list)
New! Now included as standard: vehicle-specific light distribution patters such as Ford Matrix, Skoda Matrix, or Skoda Kink!
Digital headlight testing with MLD 9000: intelligent, fast and precise
- The MLD 9000 (1692104355) supports leveling accuracy through software correction via a built-in inclinometer
- Precise green alignment lasers for accurate alignment with the vehicle. Green laser diodes are particularly well visible to the human eye because the eye has its maximum spectral sensitivity in the green range
- Cross laser function for precise positioning in the center of the headlight
- For all light sources (Xenon, Bi-Xenon, LED, Bi-LED, Halogen) and glare-free high-beam systems (Dynamic Light Assist - DLA, Matrix1, HD-Matrix2, ILS Ford)
- All types of vehicles (passenger cars, trucks, motorcycles)
- All types of headlights (main headlights, fog lamps, auxiliary lamps)
- High-resolution (5 megapixel) CMOS camera for real-time digital image processing
- Measurement results in real time optimized with live images
- Comparison between measured and limit values and unambiguous red/green evaluation
- Saving and archiving of the measured values in database
- Reporting of the measurement result possible via PDF
- Time-saving quick measurement functionality
- Precise definition of the cut-off line without disrupting blue fringe
- Workshop-proof touch-screen display (7")
- Continuously swiveling display for a variety of applications (such as the MOT for testing or in the workshop for adjustment) and for adapting to the local lighting conditions
- Intuitive and simple user guidance
- Visual and acoustic signals support the measurement procedure
- Independent operation thanks to battery
- Measured values: Horizontal and vertical deviation (pitch angle), intensity, roll angle, yaw angle
- Ports: LAN, USB, RS232
- Live firmware update possible
Highest mechanical precision and long-life cycle (suitable for future legal requirements):
- A new developed torsion-free and specially hardened aluminum column
- Easy to use, robust sliding system for precise height adjustment and comfortable working
- Robust and durable counter weight system with toothed belt
- Determination of the headlight installation height via adjustable, specially made aluminum scale or use of the optional height measuring sensor
- Optional: fine adjustment of the column with 1 angle minute accuracy
Networking: Test results via WLAN with quick and aptly arranged results on the PC
- Save measurement printouts in a network folder
- Mirror software on a PC
Certificate: CE, TÜV, EMC, FCC, FDA
| Operating temperature | 5 - 45 °C |
|---|---|
| Electrical connection | 100 - 240 V | 50 - 60 Hz |
| Battery voltage (DC) | 12 V |
| Height of light center | 240 - 1500 mm |
| Measuring range lowest stand/highest stand | 800 - -800 mm |
| Light intensity | 0 - 150000 cd |
| Illumination | (1m) 0 - 150000 / (25m) 0 - 240 lx |
| Storage temperature | -25 - 45 °C |
| Version | - Digital |
| Packaging length | 1900 mm |
| Packaging width | 700 mm |
| Packaging height | 600 mm |
| Gross weight | 62 kg |
| Measuring range low beam left/right | 1000 - -1000 mm |
| Measuring range high beam left/right | 1000 - -1000 mm |
| Relative humidity storage | 20 - 80 % |
| Relative humidity, use | 30 - 60 % |
| Radiant power alignment laser | 2 mW |
| Operating voltage alignment laser | 3 - 5 V (DC) |
| Projection alignment laser | 130° x 0,4 mrad |
| Laser diode alignment laser | 520 nm |
| Projection cross laser | 90° x 0,4 mrad |
| Laser diode cross laser | 635 nm |
| Radiant power cross laser | 5 mW |
| Operating voltage cross laser | 3 - 5 V (DC) |
| Weight | 42 kg |
| Operating temperature | 5 - 45 °C |
|---|---|
| Electrical connection | 100 - 240 V | 50 - 60 Hz |
| Battery voltage (DC) | 12 V |
| Height of light center | 240 - 1500 mm |
| Measuring range lowest stand/highest stand | 800 - -800 mm |
| Light intensity | 0 - 150000 cd |
| Illumination | (1m) 0 - 150000 / (25m) 0 - 240 lx |
| Storage temperature | -25 - 45 °C |
| Version | - Digital |
| Packaging length | 1900 mm |
| Packaging width | 700 mm |
| Packaging height | 600 mm |
| Gross weight | 62 kg |
| Measuring range low beam left/right | 1000 - -1000 mm |
| Measuring range high beam left/right | 1000 - -1000 mm |
|---|---|
| Relative humidity storage | 20 - 80 % |
| Relative humidity, use | 30 - 60 % |
| Radiant power alignment laser | 2 mW |
| Operating voltage alignment laser | 3 - 5 V (DC) |
| Projection alignment laser | 130° x 0,4 mrad |
| Laser diode alignment laser | 520 nm |
| Projection cross laser | 90° x 0,4 mrad |
| Laser diode cross laser | 635 nm |
| Radiant power cross laser | 5 mW |
| Operating voltage cross laser | 3 - 5 V (DC) |
| Weight | 42 kg |
-
Rail kit 3 m 1692105080 1692105080
-
Extension kit for rail kit | 1.5 m 1692105112 1692105112
Extension kit for rail base kit (3 m)
-
Cover | MLD 9000 1692105201 1692105201
- Dust protection
- Protection against direct sunlight
-
Alignment kit for alignment on the vehicle center line Ford requirement | for MLD 9000 1692105252 1692105252
- Exact alignment to the vehicle center line: with laser module and rear target post
- Designed for Ford vehicles with glare-free high beam, usable for all manufacturers vehicles to increase the precision
- Attached to the rear of the vehicle using magnets or suction cups
- Fine adjustment for exact positioning to the vehicle center
- High quality, highly visible, green vertical laser
- Low laser class - 1M
Note: Rail system is mandatory to use this alignment solution (Ford requirement)
-
P-Assist laser module for symmetry alignment 1690381174 1690381174
-
Height-messuring sensor | MLD 9000 1692105278 1692105278
- Automatic detection of the headlight installation height
- Automatic display of the measured height value on the device display
- Installation height value is shown in the report
Note: for MLD 9000 only
-
Yaw angle fine adjustment | MLD 9000 1692105202 1692105202
For fine adjustment of the yaw angle, including a locking mechanism
-
Printer | MLD 9000 1692105268 1692105268
