Beissbarth

Ultimate productivity

Q.Lign 360°

NEW "Q.LIGN 360°"

WHEEL ALIGNER INNOVATION

In times of electromobility, wheel alignment is more important than ever for driver safety and performance.

High torque and weight exert extreme forces on suspension components and tires. Without regular alignments, excessive wear of tires and suspension components is inevitable. Wheel alignment therefore offers increasingly important service potential for workshops, and the new "Q.Lign 360°" helps to fully exploit exactly that.



WHEEL ALIGNER Q.Lign 360° AS AN OFF-THE-LIFT SOLUTION

The "Q.Lign 360°" extends the Beissbarth wheel alignment range with a stand-alone off-the-lift solution. Building on the success of the innovative "Q.Lign" electronics and software platform, the new wheel aligner enables you as an automotive workshop to perform wheel alignments faster and more efficiently than ever before!



WHEEL ALIGNMENT NEXT LEVEL

Instead of being mounted on the side of the platform, four cameras look at the vehicle from the front. The special design of the cameras enables measurement from a distance of 1.8 to 3.3 meters from the front axle - without height adjustment and regardless of short or long wheelbases. Motors, winches and the constant ups and downs of the wide camera beams are now a thing of the past.

Increase the productivity and quality of your wheel alignment service to a new level - with the Q.Lign 360°!

The complete wheel alignment device in one bar

The complete wheel alignment device in one bar

✓ No trolley

✓ No PC

✓ Up to 90% more economical than PC-based systems

✓ Accessible via LAN/WLAN throughout the entire workshop

T.41

T.41

For free positioning in the workshop

  • Four cameras instead of two: all wheels always perfectly in view
  • Flexible installation from 1800 mm to 3300 mm distance
  • Measure wheelbases from 1750 mm to 4600 mm without any problems
  • Optional operation via tablet, PC, or smartphone
  • Precise measurement technology made in Germany
T.41 Kit

T.41 Kit

Wall installation for even more free workshop space

  • Space-saving wall mounting instead of column mounting
  • Measurements from up to 4 m
  • 360° stage access at all times
  • Operation via tablet instead of monitor, even under the vehicle
  • No trolley, no PC, no space problems
  • Minimal effort, maximum integration

Beissbarth camera technology

BETTER VISION AND HIGHER PRECISION



The front toe values depend on the rear axle. The better you can determine the toe on the rear axle, the more accurate your measurements will be on the front axle. That's why all Q.Lign wheel aligners dedicate one camera to each wheel! Other commercially available dual-camera systems, on the other hand, have to capture and measure both the rear and front axles simultaneously with only one camera.

All in sight

Wide-angle and high-focus cameras

Two wide-angle cameras for maximum visibility:

✓ From up to 1.8 m close
✓ From zero to adjustment position
✓ Calibration and steering at ground level to prevent injuries
✓ One camera per wheel for increased precision

Two high-focus cameras for long ranges:

✓ For wheel distances up to 4600 mm
✓ Separate camera for the rear axle
✓ Simultaneously better track values on the front axle

Measure and align at all heights

Measure and align at all heights

From bottom to top, no matter the wheelbase.



All targets in sight at all times

All targets in sight at all times

Even at floor level, without moving or tilting.



Q.Grip

The final step before touchless

Our latest wheel alignment machine also features our innovative Q.Grip wheel holders for quick and easy attachment of the measuring plates.

  • 5x faster than conventional holders
  • No rim contact
  • Three gripping arms for secure and precise hold throughout the entire measurement process
  • No need to remove wheel caps
  • From 21“ to 33” in less than a second, without cranking
Our Software

User-friendly and proven

Our Software

Based on the existing Q.Lign software platform.

  • Clear and easy-to-understand reports.
  • Intuitive software, optimized processes, increased productivity.
  • For all devices: PC, tablet, or smartphone.
  • Stream-to-X: Access the software from anywhere in the workshop.

Q.Lign 360° wheel alignment

Welcome to the future of wheel alignment!

Are you interested? Contact us!

Via mail: sales@beissbarth.com

Or visit our product page: Q.Lign 360°
