Wheel Balancer MT Zero 6 Touch AWLP | BMW

First of a new generation of wheel balancers, specially developed for intensive use | Rim diameter 8 - 40/10 - 30" (manual/automatic) | with pneumatic wheel clamping, sonar for tyre width detection, 22" TFT touch screen

Article number: 1 694 201 320

  • Wheel balancer with sonar spoke detection and laser weight positioning
  • Comfortable with interactive 22” TFT touch screen and pneumatic flange for wheel clamping
  • For wheels of passenger cars, vans, motorcycles with rim diameters between 10" and 30" / rim widths between 1" and 15"
  • Troubleshooting via "Check Up" self-diagnostic tool
  • Automatic LED illumination when using the electronic data arm
  • Start and stop of the measurement takes place via the wheel hood

Normal balancing within 6 seconds

  • 3 lasers mark the position of the weights: 2 laser strips for clip-on weights on steel rims and 1 laser point for adhesive weights on aluminum rim
  • Sonar and sensor arm automatically determine the width of steel rims and the number of spokes of aluminium rims
  • Automatic wheel positioning (ATP)
  • Pneumatic flange
  • 3 operators, 25+ menu languages

Large, interactive 22" touch screen

  • With numerous helpful video animations
  • Touch function can also be used with gloves.

Scope of delivery:

  • MT Zero 6 with pneumatic wheel clamping
  • Special centering kit for BMW, PCD 4 x 100 | 5 x 120 | 5 x 112 / 120 mm
  • 5x centering bolts, spring-loaded 100mm
  • Centering sleeves Ø56-57mm, Ø72,5-74mm, Ø66,5mm
  • Quick clamping nut with clamping cover and rubber ring
  • 3 laser pointers, 1 sonar
  • LED interior illumination
  • Weight pliers
  • Calibration weight

Pneumatic wheel lift can be purchased optionally

Rim width1 - 15 "
Max. wheel diameter1150 mm
Weight160 kg
Measuring speed220 rpm
Measuring time6 s
Max. rim diameter30 "
Max. wheel width490 mm
Max. wheel weight80 kg
Depth1300 mm
Height1840 mm
Power supply230 V | 50 - 60 Hz
Width1400 mm
Motor power0,7 kW
Air pressure requirement8 - 10 bar
Min. rim diameter10 "
Rim width - manual input2 - 20 "
Rim diameter - manual input8 - 40 "
Phases1
Wheel lift for wheel balancer MT Zero series1 695 601 012
Centering sleeve for Mini Countryman | 72.5 mm | 71.5 - 74.6 mm1 695 000 007
Centering sleeve Ø 66,5mm | for BMW1 695 600 214
Set clamping plate | for BMW1 695 901 690
Flange case Light Truck1 695 656 569
Centering cone for Toyota Land Cruiser und Offroad-Fahrzeuge | Ø 95 - 132 mm1 695 653 449
Centering cone set Light Truck | Ø 95 - 174 mm | 3 pcs.1 695 654 849
Cone spacer for truck cone 16956063001 695 606 200
Universal flange Passenger car | for closed 3-, 4-, 5-hole rims1 695 654 043
Specific clamping plate set QuickPlate | variable | for 3-, 4-, 5-hole rims | 3 pcs.1 695 655 294
Centering kit Light Truck1 695 656 783
Centering system DuoExpert | 3 collets | 54 - 78 mm1 695 656 698
Flange case Kit Duo Expert | for passenger cars | with pressure plates1 695 656 570
Wheel centering kit for motorbikes | Conical |Basic | Ø 14 mm1 695 000 542
